PAP Plus® A1

Introducing the PAP Plus A1® Centrifugal Compressor by FS-Elliott: a robust solution designed to deliver unmatched reliability and performance in air compression applications. With flexibility at its core, the A1 is offered in one-, two-, and three-stage configurations, ensuring tailored efficiency to suit diverse operational needs.

Experience a consistent flow of up to 100 m3/min or 3,500 CFM, making the A1 the go-to choice for facilities compression needs.

Request a Quote Download Brochure

As a member of the PAP Plus series, the A1 combines more than 60 years of operational and design experience in an extremely rugged and reliable package.

  • Flow: 45 – 100 m3/min | 1,500 – 3,500 CFM
  • Power: 190 – 595 kW | 260 – 800 hp
  • Pressure: 2.75 – 15.2 barg | 40 – 220 psig


PAP Plus A1 Features & Benefits

  • Designed to exact specifications – from API 672 to end users’ own complex needs.
  • Straight-through intercooler tube accommodates periodic cleaning, rather than replacement.
  • State-of-the-art, backward leaning impeller design that provides a broad range of superior aerodynamic performance characteristics.
  • Adjustable inlet guided vane adjust to plant conditions and load variations to save energy.
  • Full-capacity auxiliary oil pump continues normal, safe operation in the event of a main oil pump failure.
  • Filter monitoring package allows operators to receive real-time differential pressure of the oil and air filters.
  • Microprocessor-based smart transmitters capable of performing evaluations and producing diagnostics allow the operator to understand the condition of their compressed air system from a remote location.
  • Horizontally split gear case and internal components are integral features of the only truly field-serviceable gear box in the industry.
  • Regulus Control System allows the operator to control and manage the performance of one or multiple compressors, at the unit or remotely, to meet air demands while maximizing savings.
  • ISO 8573-1 CLASS 0, 100% oil-free air minimizes downtime from oil contamination in the production line and eliminates the need for off-site condensate disposal.
  • Engineered coatings designed for extreme conditions provide extended service life of internal and external surfaces, reduced maintenance, and corrosion prevention.




Case Study: Ethylene Plant Saved Over $100K/Year & Increased Demand


  1. Case Study

    Learn how the world's largest single-site ethylene plant saved over $100K/year and increased demand.

    Download the full case study.

  2. Background

    One of the world’s largest single-site ethylene facilities needed to upgrade its air system.

    Download the full case study.

  3. Manufacturing Challenge

    They needed to increase capacity while reusing the existing layout for minimal civil changes without disturbing key plant components and complying with API 672 Basic Duty requirements.

    Download the full case study.

  4. Results

    The plant was able to save over $100K in yearly maintenance and energy savings while using its existing layout, saving another $150K in installation costs.

    Download the full case study.

Learn how the world's largest single-site ethylene plant saved over $100K/year and increased demand.

Download the full case study.
